Strand

DDM PDP11 Electronics Rack

Control card dated 1974. Believed to be from the Stadttheater Baden-Baden. 240 control channels. Ampex modules are ferrite core blocks used for the show memory (similar to those used in MMS). Ferrite core blocks were used because they were non-volatile and retained their contents when the power was off.


  Documents & Photos

Strand PDP11 DDM Electronics Rack
Strand PDP11 DDM Electronics Rack (August 2014)
From The NEET Collection
Strand PDP11 DDM Electronics Rack
Strand PDP11 DDM Electronics Rack (August 2014)
From The NEET Collection
Strand PDP11 DDM Electronics Rack - Rear
Strand PDP11 DDM Electronics Rack - Rear (August 2014)
From The NEET Collection

  This item is at White Light
